For WorldTour sprinters and high-speed triathletes who know that every second counts, the EnviLiv Advanced SL was made to overtake competitors, surpass expectations, and transcend reality. Designed with next-level, full-system integration for refined aerodynamics and reduced weight, this is our fastest, most efficient, most ambitious EnviLiv to date.
RACE-TUNED EFFICIENCY Reengineered for lighter weight and greater efficiency, the all-new EnviLiv Advanced SL introduces an integrated seatpost (ISP) design that eliminates traditional seatpost hardware, reducing overall mass while enhancing ride feel through increased compliance and vibration damping. This is the first time ISP technology appears on the EnviLiv platform, bringing proven WorldTour performance benefits to Liv’s most advanced aero race bike.
SYSTEM-INTEGRATED AERODYNAMICS The EnviLiv Advanced SL is designed as a complete aerodynamic system, with every component working together to reduce drag at race speed. From the aero frameset to the onepiece Liv Contact SLR Aero cockpit, wheelsystems, and tires, each element is integrated to optimize airflow across the entire bike. The result is aerodynamic performance that’s realized not in isolation, but as a unified system built for real-world racing.
COMPOSED CONTROL Lowered seatstays add vertical compliance that smooths road vibration and improves aerodynamic efficiency, keeping the bike composed at speed when the road gets rough. With clearance for tires up to 32mm, the EnviLiv Advanced SL delivers added confidence across variable surfaces— without compromising precision, speed, or its race-ready character.
| Colours | Prism Pearl |
| Sizes | XS, S, M |
| Frame | Advanced SL-grade Composite, 12x142mm thru-axle, UDH compatible, integrated seatpost, disc |
| Fork | Advanced SL-grade composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc |
| Shock | N/A |
| Handlebar | Liv Contact SLR Aero 0, one piece bar XS:36/38cm, S:36/38cm, M:37/40cm |
| Grips | Stratus Lite 2.0 |
| Stem | Liv Contact SLR Aero 0, one piece bar XS:80mm, S:90mm, M:100mm |
| Seatpost | Advanced SL-grade composite, integrated design, -5/+15mm offset |
| Saddle | CADEX AMP 155 |
| Pedals | N/A |
| Shifters | SRAM RED AXS HRD, ED-RED-E1 |
| Front Derailleur | SRAM RED AXS, FD-RED-E-E1 |
| Rear Derailleur | SRAM RED AXS, RD-RED-E-E1 |
| Brakes | SRAM RED AXS HRD, ED-RED-E1, SRAM PaceLine X rotors [F]160mm, [R]140mm |
| Brake Levers | SRAM RED AXS HRD, ED-RED-E1 |
| Cassette | SRAM RED XG-1290, 12-speed, 10-36 |
| Chain | SRAM RED-E1, 12-speed |
| Crankset | SRAM RED E1, DUB , 35/48 with power meter XS:165mm, S:165mm, M:170mm |
| Bottom Bracket | SRAM DUB ceramic, press fit |
| Rims | CADEX Max 50 WheelSystem, [F]50mm, [R]50mm |
| Hubs | [F] CADEX R3 Hub, CenterLock, 12mm thru-axle [R] CADEX R3-C48 Aero Hub, 48t ratchet driver, CenterLock, 12mm thru-axle |
| Spokes | CADEX Super Aero Carbon Spoke |
| Tyres | CADEX Aero, tubeless, 700x28c (28mm), folding |
| Extras | Computer mount, water bottle cages, tubeless prepared, 32mm max tyre size |
| EnviLiv Advanced SL | XS | S | M |
| Seat tube length | 680 | 710 | 740 |
| Seat tube angle (Degrees) | 75 | 75 | 74 |
| Top tube length | 510 | 524 | 540 |
| Head tube length | 115 | 130 | 150 |
| Head tube angle (Degrees) | 71 | 72 | 73 |
| Fork rake | 49 | 49 | 49 |
| Trail | 67 | 60 | 57 |
| Wheelbase | 975 | 977 | 984 |
| Chainstay length | 405 | 405 | 405 |
| Bottom bracket drop | 72 | 70 | 70 |
| Stack | 512 | 527 | 548 |
| Reach | 373 | 378 | 383 |
| Standover height | 733 | 761 | 787 |
| Handlebar width | 360 | 360 | 370 |
| Stem length | 80 | 90 | 100 |
| Crank length | 165 | 165 | 170 |
| Wheel size | 700 | 700 | 700 |
