Giant TCR Advanced SL 1 - Blue Dragonfly

Size
Price
Regular price $9,499.00
Regular price Sale price $9,499.00
/
Tax included.

**AVAILABLE FOR IN-STORE COLLECTION ONLY**

BUILT TO GO FASTER. WHETHER YOU’RE CLIMBING, CORNERING OR LAUNCHING AN ATTACK, THIS ALL-NEW COMPOSITE ROAD RACER IS MADE FOR THAT MOMENT. LIGHTWEIGHT, EFFICIENT, AND INTEGRATED FOR SPEED, IT’S ENGINEERED TO GIVE YOU A COMPETITIVE EDGE IN EVERY SITUATION.
KEY PERFORMANCE FACTORS


SYSTEM OPTIMIZATION
The frameset, wheels, cockpit and other parts were engineered, developed and tested together to perform as a system. The all-new Contact AeroLight stem allows for cable routing that integrates the top cap, cables and spacers in a more aerodynamic, user-friendly setup.


WINNING EFFICIENCY
Featuring a greater stiffness-to-weight ratio than the previous generation, along with new aero tube shaping and a lighter overall weight, this uncompromising race bike delivers explosive acceleration and unyielding pedaling stiffness. The result is race-winning performance in the moments that count.


INTEGRATED AERODYNAMICS
All tube shapes were engineered and developed using Computational Fluid Dynamics (CFD) modeling and wind-tunnel testing. From the truncated ellipse shape of frameset tubing to a new cockpit design and component integration, it all adds up to a more streamlined profile that improves overall aero performance compared to the previous generation.

Model Name TCR Advanced SL 1
Colours Blue Dragonfly
Sizes XS, S, M, M/L, L, XL
Frame Advanced SL-Grade Composite, 12x142mm thru-axle, integrated seatpost, disc
Fork Advanced SL-Grade Composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc
Shock N/A
Handlebar Giant Contact SLR XS:37/40cm, S:37/40cm, M:39/42cm, M/L:39/42cm, L:41/44cm, XL:41/44cm
Grips Stratus Lite 2.0
Stem Giant Contact SLR AeroLight                                                                                           XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm
Seatpost Advanced SL-Grade composite, integrated design, -5/+15mm offset
Saddle Giant Fleet SLR
Pedals N/A
Shifters Shimano Ultegra Di2 ST-R8170
Front Derailleur Shimano Ultegra Di2 FD-R8150
Rear Derailleur Shimano Ultegra Di2 RD-R8150
Brakes Shimano Ultegra Di2 hydraulic, Shimano RT-CL800 rotors                                                 [F]160mm, [R]140mm
Brake Levers Shimano Ultegra Di2 hydraulic
Cassette Shimano Ultegra, 12-speed, 11x34
Chain Shimano Ultegra, CN-M8100
Crankset Shimano Ultegra, 36/52 with Giant Power Pro power meter                                                                XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm,  L:175mm, XL:175mm
Bottom Bracket Shimano, press fit
Rims Giant SLR 0 40 WheelSystem, [F]40mm, [R]40mm
Hubs [F] Giant Low Friction Hub, CenterLock, 12mm thru-axle
 [R] Giant Low Friction Hub, 40t ratchet driver, CenterLock, 12mm thru-axle
Spokes Giant Aero Carbon Spoke
Tyres CADEX Race GC, tubeless, 700x28c (28mm), folding
Extras Computer mount, tubeless prepared, 33mm max tyre size


TCR Advanced SL  XS  ML L XL
Seat tube length  680  710  740  770  800  830
Seat tube angle (degrees) 74.50  74.00  73.50  73.00  73.00  72.50
Top tube length 520  535  550  565  580  600
Head tube length  120  130  145  165  185  200
Head tube angle (degrees)  71.00  72.25  73.00  73.00  73.00  73.00
Fork rake  45  45  45  45  45  45
Trail  72  64  59  59  59  59
Wheelbase  976  977  980  991  1006  1020
Chain stay length  405 405 405 405  405  405
Bottom bracket drop  72.0  69.5  69.5  67.0  67.0  67.0
Stack  517  528  545  562  581  596
Reach  376  383  388  393  402  412
Stand over height  703  722  743  771  798  822
Handlebar width  400  400  420  420  440  440
Stem length  80  90  100  110  110  120
Crank length  170.0  170.0  172.5  172.5  175.0  175.0
Wheel size  700C 700C 700C 700C 700C 700C
